SHANHAI New Arrival Sierra AirPrime 4G EM7565 LTE-Advanced Pro Module

FOB Reference Price:Get Latest Price
US $220-300 / Pieces | 1 Piece/Pieces Sierra AirPrime 4G module (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Huawei
Model Number:
4G EM7565
Product name:
New Arrival Sierra AirPrime 4G EM7565 LTE-Advanced Pro Module
Dimensions:
42 x 30 x 2.3 mm [Type
Chipset:
Qualcomm MDM9230
LTE-U/ LTE-LAA Bands:
46, 252, 255 (5GHz)
Temp Range:
30C to +70C (operating class A) TBC
FDD/TDD LTE Bands:
1-5, 7, 8, 9, 12, 13, 17, 18, 19, 20....
Interface:
USB 3.0, USB 2.0 & PCIe(Future)
Certification:
CE FCC RoHS
Warranty:
1 year
Service:
Good after-sales service
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month huawei 4G EM7565 module
Packaging & Delivery
Packaging Details
BOX for LTE-Advanced Pro Module
Port
shenzhen Guangdong
Lead Time :
Shipped in 2 days after payment

New Arrival Sierra AirPrime 4G  EM7565 LTE-Advanced Pro Module



Product Description



AirPrime®EM7565 Specifications
Cellular
•Possible LTE DL Product variants:Cat 15 –800Mbps (80MHz 4CA with 256 QAM)Cat 12 –600Mbps (60MHz 3CA with 256 QAM)Cat 10 –450Mbps (60MHz 3CA with 64 QAM)
•Uplink speed up to 150 Mbps (Cat 13)(64 QAM + intra-band contiguous 2CA)
•FDD/TDD LTE Bands:1-5, 7, 8, 9, 12, 13, 17, 18, 19, 20, 26, 28, 29, 30, 32, 41, 42, 43, 66
•LTE-U/ LTE-LAA Bands: 46, 252, 255 (5GHz)
•DC-HSPA+ (42/5.76 Mbps)1,2,3,4,5,6,8,9,19
Hardware Specs
Dimensions: 42 x 30 x 2.3 mm [Type 3042]
Chipset: Qualcomm MDM9230
Main interfaces:
•USB 3.0, USB 2.0 & PCIe(Future)
•GPIOs for antenna tuning and SAR control
Temperature ranges:
•–30C to +70C (operating class A) TBC
•–40C to +85C (operating class B) TBC
•Storage Temperature: –40C to +85C
Key Features
Single WW SKU for North America, Europe, APAC & ROW
•GNSS (GPS, Glonass, Galileo, BeiDou) Dedicated antenna connector with bias or shared on diversitySupport for SUPL and XTRA
•Embedded SIM (eUICCcapable) -Optional
•Low power consumption
•Storage for multiple FW images in on board Flash
•Gobi API, MBIM interface
•Basic and Extended AT Commands
•Host OS: Skylight for Windows 7, 8/8.1, 10; Linux and Android
Standard features:
•Secure boot prevents unauthorized code on the target
•Firmware image switching for network flexibility
•Dual SIM single standby (DSSS) enhances roaming coverage
•Free, unlimited FOTA through AirVantage®FOTA Edition
Certifications and Approvals
Planned: FCC, IC, CE, PTCRB, GCF, NCC
•Planned: Verizon, AT&T, Vodafone, Telstra, docomo
