Quick Details

  • Place of Origin: Germany
  • Brand Name: Cinterion
  • Model Number: TC65I
  • Product name: GOOD OFFER FOR CINTERION TC65I WIRELESS MODULE IN STOCK
  • Application: Wireless Control
  • Quad-Band: 850/900/1800/1900MHZ
  • Dimensions: 33.9*35.0*3.3mm
  • Operating Temperature: -40°C to +75°C
  • Type: GSM/GPRS module

Packaging & Delivery

Packaging Details Box
Delivery Time Shipped in 2 days after payment

 GOOD OFFER FOR CINTERION TC65I WIRELESS MODULE IN STOCK





Product Description





Specifications



GPRS Class 12 for both 86 kbps in uplink and downlink

Quad-Band (850/900/1800/1900 MHz)

80 pin B2B connector

RF connector

Additional antenna soldering pad

TCP/IP over AT

Java IMP-NG Virtual Machine open platform

USB, I2C, SPI, two serial interfaces

Extended temperature range: -40°C to +75°C

Radio Link Stability (RLS) monitoring (e.g. for jamming detection)

Remote SIM access



General specfications:



Control via AT commands (Hayes 3GPP TS 27.007 and 27.005)

GPRS multi-slot Class 12 Class 12 Class 12

Circuit Switched Data Up to 14.4 kbps

SMS

Fax Group 3, class 1 Group 3

SIM Application Toolkit (release 99)

TCP/IP stack access via AT commands

Internet services: TCP, UDP, HTTP, FTP, SMTP, POP3

Supply voltage range: 3.2 . 4.5 V

Operational temperature range: -40°C to +75°C, switch off: > +80°C

Dimensions: 33.9 x 35.0 x 3.3 mm

Weight: 7.5 g



Specification for GPRS data transmission

GPRS Class 12 Max. 86 kbps(DL and UL)

Coding schemes CS 1-4



Specification for voice

Triple-rate codec for HR, FR, and EFR

Adaptive multi-rate AMR

Hands-free operation, Echo cancellation & Noise reduction



Java# features

Java# profile IMP-NG & CLDC 1.1 H

Secure data transmission with HTTPS, SSL, and PKI

Multi-threading programming and program execution



Special features (extract)

Character framing 7E1 and 8E1 at serial interface

SIM Access Profile integrated

RLS Monitoring

Advanced Temperature Management



Interfaces

Antenna: U.FL-R-SMT + 50 Ω solder pad

Audio: 2 x analog, 1 x digital

Serial interfaces (ITU-T V.24 protocol) 2

SIM card interface 3 V, 1.8 V

USB 2.0 full speed

I2C & SPI bus

Analog in and analog out (ADC and PWM) 2 ADC, 1 PWM

Multiple GPIOs



Approvals

CE, R&TTE, GCF, UL, FCC, IC, PTCRB
